البيـــــــــــــــــــــــــــــان |
المواصفات |
|
|
Personal Computer |
COMPUTER : Processor : Intel Core 2 Duo Processor T6400 Memory : 4 GBPC6400 DDR2 800MHz SDRAM. Display Type : WXGA with TruBrite Technology Hard Drive : 400GB HDD (5400rpm) Optical Drive : DVD-Super Multi drive +/-R double layer) Modem : 56 Kbps Data/Fax Modem internal Sound Card : Integrated Speaker : Headphone Speaker Ethernet Card : Integrated 10/100/1000 Base T network (Ethernet) interface included Wireless. Monitor : 17" Flat Monitor LCD Keyboard: Multimedia and Internet keyboard Mouse : Optical Mouse DVD Drive : DVD + CD – RW Operating System :Windows XP Professional , all supported drivers, Microsoft Office and Antivirus |
|
|
Language lab control system (includes intralab VR) |
CONTROL UNIT: ON/Off switch with integral power indicator lamp Addressable stations Standard ( no expander ) up to 63 Rs-232 Serial Port ( control computer) Rs-232 Serial Port (DL/B) Smart Class C-Link (to JU) smart Class R-Bus part 1 |
|
|
Language lab communication module (includes intralab VR) Audio Matrix |
Smart Class R-Bus Port 2
|
|
|
Audio Matrix – Teacher |
INTERFACE Video Signal Characteristics : Video Bandwidth – 200 MHz Resolution /Refresh Rate up to 1600 x 1200 @ 85Hz Video Cabling – single CAT-5e (UTP) Audio Signal Characteristics : Audio Bandwidth – 20 Hz to 20.000 Hz ± 3 db Audio Cabling – single CAT-5e (UTP) Keyboard/Mouse Signal Characteristics: K/V/M Interface Standard – PS/2 K/M Cabling –single Cat-5e Connectors : |
|
|
Audio Matrix – Student |
K/V/M Hub (video ) RJ-45 jack |
|
|
Heavy duty Student |
K/V/M Hub (keyboard/Mouse) – RJ-45 jack |
|
|
Headset ( 2 –ear) |
Audio Hub (audio) Rj-45 jack |
|
|
Controller |
Workstation port (K/V/M) |
|
|
KVM Hub |
I-Link port (Call Box or Terminal ) RJ-45 jack |
|
|
Dual interface USB |
A-Link port ( USB adapter and/or audio pairing) rJ-11 jack |
|
|
Quad interface USB |
Supplied Accessories : All necessary cables included |
|
|
KVM Cable (USB) |
|
|
|
Cat – 5E Regular Cable – Length in feet |
HUB Video Signal Characteristics: Video Bandwidth – 200 MHz Resolution/Refresh Rate – up to 1600x1200@ 85 Hz Video Cabling to Workstation Interface – single CAT-5e(UTP) Keyboard/Mouse Signal Characteristics : K/M Interface Standard – PS/2 Optional (not yet released )- USB K/M Cabling to Workstation Interface – single CAT-5e (UTP) Connectors : Workstation Interface Port – Video (8) – 8X RJ-45 jack Workstation Interface Ports- Keyboard/Mouse (8)-8X RJ-45 jack Controller Port TTL (direct connection to controller ) – RJ-45 RS-485 ( connection to controller via ) Power (12VDC) Audio Hub Interconnect – RJ-45 K/V/M Hub Expansion Upstream Video Downstream Video Upstream Keyboard/Mouse –RJ-45 Downstream Keyboard/Mouse-RJ-45
(AUDIO HUB) Audio Signal Characteristics : Audio Bandwidth – 20 Hz to 20.000 Hz ± 3 db Audio Cabling to Workstation Interface – single CAT-5e (UTP) Connectors: Workstation Interface Ports (8)-8X RJ-45 jack Power (23 VDC) – Din-5f K/V/M Hub Interconnect – RJ -45 jack Audio Hub Expansion (upstream – RJ-45 jack) Audio Hub Expansion (downstream – RJ-45 jac) Indicators : AC Mains power Available Power On Diagnostics Supplied Accessories : Universal Input Power Supply ( specify mains connector type) K/V/M Hub Interconnect Cable – 6 feet/1.8 m Audio Hub Expansion Cable (included with first hub) -6 feet/ 1.8m System CAT-5e or CAT -6 Cables ordered separately OTHER SYSTEM SPECIFICATIONS : Multidirectional keyboard and mouse switching (Instructor to student , student to student, student to instructor) Distributed power supply Teamwork function available |
|
